Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
Installing the Thermal Module
The thermal module comes in two different models: a UMA model and a Discrete model. Install
the thermal module of each model according to the following procedures.
For the Discrete model
1. Reapply Shinetsu 7762 thermal grease on the VGA thermal pads as shown in Figure 4.40.
If you use a new thermal module, remove the release papers on the thermal pads first.
thermal grease thermal pads
thermal grease
thermal pads
Figure 4.40 Reapplying Shinetsu 7762 grease on the thermal module
and remove any release papers
2. Seat the thermal module on the motherboard in the correct position and secure the four
M2.5x6 spring screws and the three M2.5x6.5spring screws according to the number
sequence sealed on the thermal module as shown in Figure 4.41.
Satellite A660/ProA660 Series Maintenance Manual 4-51

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
