4 Replacement Procedures
ODD bezel hook
ODD bezel hook
Figure 4.17 Hooks on the inside of the Tray-load ODD bezel
Assembling the ODD (Tray-load)
Assemble the ODD according to the following procedures.
1. Seat the ODD bracket in the correct position and secure it with two M2x3 screws.
Satellite A660/ProA660 Series Maintenance Manual 4-25
