Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
5. Remove the four M3x3 screws with torque value 3.5kgf in order as indicated in Figure
4.5 and separate the HDD foil from the HDD.
NOTE: The HDD foil screws on this module are specific to the system. Screws from older
systems are not compatible and must not be used on the HDD.
M3x3*2
M3x3*2
Figure 4.5 Removing the HDD foil
CAUTION: Do not apply pressure to the top or bottom of the drive.
Installing the HDD
Install the HDD according to the following procedures and Figure 4.6.
CAUTION: To avoid damage, always hold the HDD only by its sides.
1. Place the HDD foil on the HDD.
2. Secure the HDD foil with four M3x3 screws in order as indicated in Figure 4.6.
NOTE: The HDD foil screws on this module have oversized heads and are specific to the
system. Screws from older systems are not compatible and must not be used on the HDD.
Satellite A660/ProA660 Series Maintenance Manual 4-13

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
