Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
4.17 Thermal Fan
Removing the Thermal Fan
Remove the thermal fan according to the following procedures and Figure 4.32.
1. Remove the two M2x5 screws from the thermal fan as shown in Figure 4.32.
2. Disconnect the cable from the motherboard.
3. Remove the thermal fan.
M2x5*2
Figure 4.32 Removing the thermal fan
Installing the Thermal Fan
Install the thermal fan according to the following procedures.
1. Seat the thermal fan in the correct position.
2. Secure the thermal fan with two M2x5 screws.
3. Connect the cable to the motherboard.
Satellite A660/ProA660 Series Maintenance Manual 4-42

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
