4 Replacement Procedures
Figure 4.19 Disconnecting the cables and removing the upper logic assembly screw
4. Pry up the logic upper assembly from the bottom edge and remove it as shown in Figure
4.20.
Figure 4.20 Removing the logic upper assembly
Satellite A660/ProA660 Series Maintenance Manual 4-27
