Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
Installing the WLAN Antennas
Install the WLAN antennas according to the following procedures.
1. Place the WLAN antenna heads in the correct position and adhere them to the display
panel.
2. Route the WLAN antennas in the routing channels. Take care to route the antennas
properly through the channels as indicated in Figure 4.51.
CAUTION: The black and white WLAN antennas should run parallel to the edge of the LCD
display assembly. The optional 3G antennas (where present) will diverge from the WLAN
antennas at the top of the unit, as shown in Figure 4.51 .
WLAN (white)
WLAN (black)
3G (optional)
Figure 4.51 Routing the WLAN antennas onto the display assembly
NOTE: The black antenna should be on the left hand side of the screen cover and the white
antenna should be on the right.
Satellite A660/ProA660 Series Maintenance Manual 4-63

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
