4 Replacement Procedures
Satellite A660/ProA660 Series Maintenance Manual 4-28
Installing the Logic Upper Assembly
Install the logic upper assembly according to the following procedures.
1. Seat the logic upper assembly from the back edge and adjust to the correct position. Snap
the logic upper assembly firmly into place.
2. Attach the four cables and secure the logic upper assembly with two M2.5x8 screws as
indicated in Figure 4.19. Models featuring the optional FeliCa card will have a fifth
connector. Connect the FeliCa card connector as shown in Figure 4.19 (where applicable).
3. Close the laptop and turn it upside down. Secure the logic upper assembly with thirteen
M2.5x8 screws as indicated in Figure 4.18.
