Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
Disassembling the ODD (Slot-load)
NOTE: Do not disassemble the ODD when it is working normally. Disassemble or replace
the ODD only if it fails.
Disassemble the ODD according to the following procedures and Figure 4.21.
1. Remove the two M2x3 screws securing the ODD bracket to the ODD.
2. Remove the ODD bracket from the ODD.
3. Remove the M2x3 screw securing the ODD board to the ODD.
4. Remove the ODD board from the ODD.
M2x3*3
Figure 4.21 Disassembling the Slot-load
ODD
Satellite A660/ProA660 Series Maintenance Manual 4-30

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
