Toshiba C70-A Series Maintenance Manual

4 Replacement Procedures
4.22 CPU
Removing the CPU
Remove the CPU according to the following procedures and Figure 4.44.
CAUTION:
When removing the CPU, keep the following in mind:
The CPU can become very hot during operation. Be sure to let it cool down before starting
repair work.
1. Use a flat blade screwdriver to unlock the CPU by rotating the cam on the CPU socket
counterclockwise to the unlock position, aligning the divot on the cam with the
‘unlocked’ icon as shown in Figure 4.44.
2. Remove the CPU.
Figure 4.44 Removing the CPU
Satellite A660/ProA660 Series Maintenance Manual 4-54

Toshiba C70-A Series Specifications

General

Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (varies by model)
Storage	500GB or 1TB HDD (varies by model)
Graphics	Intel HD Graphics (varies by model)
Optical Drive	DVD SuperMulti Drive
Connectivity	Wi-Fi 802.11b/g/n, Bluetooth 4.0 (varies by model)
Ports	USB 3.0, USB 2.0, HDMI, VGA, headphone/microphone combo jack
