Clearing a Paper Jam
Locating a paper jam
The equipment stops copying when the original or copy paper is jammed. Paper jams are notified on the touch panel as
follows:
The paper jam symbol helps you locate the paper jam.
1. Reversing Automatic Document Feeder (Optional) ( P. 1 3 )
2. Fuser unit ( P.19)
3. Automatic duplexing unit ( P.17)
4. Bypass tray ( P. 1 7 )
5. Drawer feeding portion ( P. 1 5 )
6. Large Capacity Feeder ( P.16) or Paper Feed Pedestal (both optional) ( P.16 )
7. Jam releasing cover ( P. 1 8 )
8. Bridge Unit (optional) ( P.21)
9. Saddle Stitch unit (Optional) ( P.28)
10. Finisher and Hole Punch Unit (both optional) ( P. 2 2 , P. 2 6, P.30)
The picture of the hardware device shown on the touch panel differs depending on the Finisher options installed.
