Toshiba e-studio 2330C Troubleshooting Guide

1 TROUBLESHOOTING FOR THE HARDWARE
18 Clearing a Paper Jam
3
Lower the paper guide and return the automatic duplexing unit to its original position.
Be sure to firmly close both sides of the automatic duplexing unit.
 Paper jam in the jam releasing cover
2
Remove the jammed paper lifting the paper guide.
1
2
1
Open the automatic duplexing unit.
2
Open the jam releasing cover.
Put your fingers into A, push it up to release the lock, and open the jam
releasing cover.
3
Open the transport guide holding the green knob.
A
1
2
