e-STUDIO163/203 FIRMWARE UPDATING December 2005 © TOSHIBA TEC
6 - 2
Important:
Pay attention to the direction of the ROM.
K-PWA-DLM-320
Fig. 6-3 Jig board: K-PWA-DLM-320
Connector Mark for ROM
installation direction
ROM
LED
06/04
