238 GX9 ASD Installation and Operation Manual
Enclosure Dimensions/Weight
Refer to the drawings of
Figure 36
to
Figure 41
for the referenced enclosure figures.
Table 17. 5 – 1200 HP ASD Weights and Enclosure Dimensions.
Model Number
GX96
Shipping Weight
Lbs/kg
Figure
Junction Box No Junction Box
060
45/21 43/20 Figure 36
080
110
160
220
270
162/74 160/73 Figure 37
330
400
500
600
750
10K
1450/658 1300/590 Figure 38
12K
15K
17K
20K
25K
2350/1066 2250/1021
Figure 3930K
40K 2560/1162 2330/1057
50K
1700/772 1500/681 Figure 40
60K
70K
80K
90K
3500/1588 3200/1452 Figure 4110L
12L
