GX9 ASD Installation and Operation Manual 27
CN7 Pinout
Listed below are the pinouts of the CN7 connector. The CN7 connector is the 25-pin D-type connector
of the Control Board (see Figure 8 on pg 26). CN7 connects to CN7A of the Terminal Board.
Table 3. CN7 pinout assignments. Default settings listed for the programmable terminals.
Pin Number
CN7
Pinout
Pin Number
CN7
Pinout
1 PP 14 II
2 FL 15 S1
3 VI 16 R
4 RR 17 S3
5 FM 18 S2
6 RX 19 N15
7 *FP 20 S4
8 AM 21 P15
9 OUT1 22 P24
10 OUT2 23 CC
11 ST 24 CC
12 RES 25 CC
13 F
Note: * Open collector output.
