Monitor Mode
The Monitor mode allows the user to monitor motor performance variables, control settings, and
configuration data during motor operation. The items are listed and described below.
Note: The Monitor mode is a read-only mode. The settings cannot be changed from the
Monitor mode. For information on how to change the values, see the section titled
Default Setting Changes on pg. 61.
Note: Any two of the Underlined
monitored items may be selected for display at the
Frequency Command screen while running via Program Utilities Main
Monitor Selections.
Note: The F701 setting will determine if the Current and Voltage values displayed
appear as A (Amps) and V (Voltage), or if the value is shown as a
% (percentage)
of the ASD rating.
Frequency at Trip — Displays the at-trip frequency.
Frequency Reference — Displays the Frequency Setpoint.
Output Current
— Displays the Output Current as a percentage of the rated capacity of the GX9
ASD.
DC Bus Voltage
— Displays the Bus Voltage as a percentage of the rated capacity of the GX9
ASD.
Output Voltage
— Displays the Output Voltage as a percentage of the rated capacity of the GX9
ASD.
AM Output
— Displays the AM output terminal value for the function assigned to the AM terminal.
FM Output
— Displays the FM output terminal value for the function assigned to the FM terminal.
Motor OL (Overload) Trip
— Displays the Motor Overload Trip value as a percentage of the
rated capacity of the motor.
Motor Load
— Displays the real-time Motor Load as a percentage of the rated capacity of the
motor.
ASD OL (Overload) Trip
— Displays the ASD Overload Trip value as a percentage of the rated
capacity of the ASD.
ASD Load
— Displays the ASD Load as a percentage of the rated capacity of the GX9 ASD.
Run Time
— Displays the Cumulative Run Time in hours.
Compensation Frequency
— Displays the Output Frequency after the application of the slip
compensation correction value (Post Compensation Frequency).
DBR OL (Overload) Trip
— Displays the DBR Overload Trip value as a percentage of the
Dynamic Braking Resistor capacity.
DBR Load — Displays the DBR Load as a percentage of the Dynamic Braking Resistor capacity.
Feedback (Inst)
— Provides a status of the Real-Time Feedback in Hz.
Feedback (1 Second)
— Provides a status of the 1-Second Averaging feedback in Hz.
Torque
— Displays the Output Torque as a percentage of the rated capacity of the GX9 ASD.
Torque Reference
— Displays the Torque Reference as a percentage of the maximum torque
available.
o
nitored
e
ms
