196 GX9 ASD Installation and Operation Manual
(FP Terminal) Pulse Output Function
Program Terminal FP Terminal Settings
This parameter sets the functionality of the FP output terminal to any one of the
user-selectable functions listed in Table 9 on pg. 221.
As the assigned function changes in magnitude or frequency, the pulse count of
the FP output terminal pulse train changes in direct proportion to changes in the
assigned function.
Note: The duty cycle of the output pulse train remains at 65 ±5.0 µS.
This parameter is used in conjunction with parameter F677.
Direct Access Number — F676
Parameter Type — Selection List
Factory Default — Output Frequency
Changeable During Run — Yes
(FP Terminal) Pulse Output Frequency
Program Terminal FP Terminal Settings
This parameter scales the FP output terminal by setting the pulses-per-second
output signal of the FP terminal.
See F676 for more information on this parameter.
Direct Access Number — F677
Parameter Type — Numerical
Factory Default — 3840
Changeable During Run — Yes
Minimum — 1000
Maximum — 43200
Units — kHz
Optional Analog Terminal Mark
Program Special Special Parameters
Not Used.
Direct Access Number — F680
Parameter Type — Numerical
Factory Default — 0
Changeable During Run — Yes
Minimum — 0
Maximum — 3
Current/Voltage Units Setup
Program Utilities Display Parameters
This parameter sets the unit of measurement for current and voltage values
displayed on the EOI.
Settings:
0 — %
1 — A/V
Direct Access Number — F701
Parameter Type — Selection List
Factory Default — %
Changeable During Run — Yes
Free Unit Multiplication Factor
Program Utilities Display Parameters
This parameter provides a multiplier for the displayed speed value shown on the
EOI of the ASD.
This parameter may be used to display the rate that a commodity is being
processed by the driven load in process units (i.e., units/time).
Example: An output frequency of 100 Hz would be displayed as 50 Hz if
using a multiplier of 0.5 for this parameter.
Note: PID frequency-limiting parameters are not affected by this
setting (i.e., F364, F365, F367, and F368).
Direct Access Number — F702
Parameter Type — Numerical
Factory Default — 0.00 (Off)
Changeable During Run — Yes
Minimum — 0.00 (Off)
Maximum — 200.00
FP
F676 F702
