Toshiba Qosmio X500 Maintenance Manual

Replacement Procedures
Qosmio X500 Maintenance Manual (960-Q08)
4-41
4. Arrange the wireless antenna cables along the guide (front) and secure them with
guide.
5. Pass the cables to the back of computer through the slot.
6. Arrange the wireless LAN antenna along the guide and contact with the connector.
7. Install the LAN board and cover ASSY of the system, secure it with the screws
 M2.5x6.5 Flat BIND screws x7
8. Install the KBD Holder and Keyboard with screws
 M2.5x3.0 Flat BIND screws x4
9. Turn the computer downside and Secure the bottom with screws
 M2.56.5 FLAT BIND screw x11
 M2.58.0 FLAT BIND screw x6
 M2.54.0 FLAT BIND screw x2
 M2.53.0 FLAT BIND screw x1
 M2.52.0 FLAT BIND screw x5
10. Install battery pack, HDD door and Optical Drive Disk with screws
 M2.54.0 FLAT BIND screw x2
 M2.53.0 FLAT BIND screw x1
NOTE: If Fingerprint or Dust left on LCD screen during disassembly and assembly
LCD units, please follow Appendix A to clean it.

Toshiba Qosmio X500 Specifications

General

Graphics	NVIDIA GeForce GTS 360M
Display Size	18.4 inches
Resolution	1920 x 1080 pixels
Storage	500GB HDD
Operating System	Windows 7 Home Premium
LAN	Gigabit Ethernet
USB Ports	4 x USB 2.0
HDMI	Yes
Processor	Intel Core i7
Optical Drive	Blu-ray Disc drive
Wireless	Wi-Fi 802.11n
Battery	Lithium-ion battery (various capacities)
Weight	10.1 lbs
RAM	Up to 8GB DDR3
