Toshiba Qosmio X500 Maintenance Manual

Board Layout
Qosmio X500 Maintenance Manual (960-Q08) B-3
Table B-1-1 System board ICs and connectors
NUM Location Function
(01) CN6 SPDIF CONN
(02) CN10 Audio&USB CONN
(03) CN11 LVDS CONN
(04) CN2 CRT CONN
(05) CN1 MDC CONN
(06) CN16 KB CONN
(07) CN14 FAN CONN
(08) U50 HDMI IC
(09) CN22 TMA CONN
(10) CN48 BATT CONN
(11) CN20 K/B LED power CONN
(12) CN25 LED/B CONN
(13) CN21 TP&FP/B CONN
(14) CN31 BCAS CONN
(15) CN29 Felica CONN
(16) CN33 Cardreader CONN
(17) CN32 New Card CONN
(18) CN15 WiFi CONN
(19) CN27 Bluetooth CONN
(20) CN24 MMB CONN
(21) CN17 WUSB CONN
(22) CN26 TV Tuner CONN

Toshiba Qosmio X500 Specifications

General

Graphics	NVIDIA GeForce GTS 360M
Display Size	18.4 inches
Resolution	1920 x 1080 pixels
Storage	500GB HDD
Operating System	Windows 7 Home Premium
LAN	Gigabit Ethernet
USB Ports	4 x USB 2.0
HDMI	Yes
Processor	Intel Core i7
Optical Drive	Blu-ray Disc drive
Wireless	Wi-Fi 802.11n
Battery	Lithium-ion battery (various capacities)
Weight	10.1 lbs
RAM	Up to 8GB DDR3
