Toshiba Qosmio X500 Maintenance Manual

Board Layout
B-4 Qosmio X500 Maintenance Manual (960-Q08)
(23) CN13 Power/B CONN
(24) U2 Audio IC
(25) U13 Clock generator
(26) U4 Embedded Controller IC
(27) U9 LAN IC
(28) U27 Card Reader /1394
(29) U35 CPU
(30) U47 North Bridge
(31) CN31 DDR CONN
(32) CN32 2nd SATA HDD CONN
(33) PCN1 DC IN CONN
(34) CN46 Main SATA HDD CONN
(35) CN47 SATA ODD CONN
(37) CN44 1394 CONN
(38) CN41 HDMI CONN
(39) CN37 USB CONN
(40) CN36 ESATA CONN
(41) CN35 RJ45 CONN
(42) PCN0 VGA Power CONN
(43) CN39 VGA CONN

Toshiba Qosmio X500 Specifications

General

Graphics	NVIDIA GeForce GTS 360M
Display Size	18.4 inches
Resolution	1920 x 1080 pixels
Storage	500GB HDD
Operating System	Windows 7 Home Premium
LAN	Gigabit Ethernet
USB Ports	4 x USB 2.0
HDMI	Yes
Processor	Intel Core i7
Optical Drive	Blu-ray Disc drive
Wireless	Wi-Fi 802.11n
Battery	Lithium-ion battery (various capacities)
Weight	10.1 lbs
RAM	Up to 8GB DDR3
