Pin Assignment
Qosmio X500
Maintenance Manual (960-Q08)
5
1 GND --- 2 USBP9- I
3 USBP9+ I 4 CPUSB# I/O
5 --- --- 6 --- ---
7 NEW SMCLK I 8 NEW SMDATA I/O
9 +NEW_1.5V I 10 +NEW_1.5V I
11 PCIE_WAKE# I 12 +NEW_3VAUX O
13 PERST# I/O 14 +NEW_3V I
15 +NEW_3V I 16 NEW_CLKREQ# O
17 CPPE#_ I/O 18 CLK_PCIE_NEW# I
19 CLK_PCIE_NEW I 20 GND ---
21 PCIE_RXP2 O 22 PCIE_RXP2 O
23 GND --- 24 PCIE_TXN2 I
25 PCIE_TXN2 I 26 GND ---
CN27 Blue Tooth Connectors
PIN No. Signal name I/O PIN No. Signal name I/O
1 GND --- 2 USBP2+ I/O
3 USBP2- I/O 4 WCS_CLK ---
5 GND --- 6 BT_RESET ---
7 WCS_DAT O 8 +3V ---
9 BT_EN O 10 GND ---
CN45 RTC Battery Connectors
