Pin Assignment
Qosmio X500
Maintenance Manual (960-Q08)
6
PIN No. Signal name I/O PIN No. Signal name I/O
1 RTC_NO2 I 2 GND ---
CN2 CRT Connectors
PIN No. Signal name I/O PIN No. Signal name I/O
1 +5V --- 2 NC
3 GND --- 4 CRT_R1 ---
5 GND --- 6 CRT_G1 ---
7 GND --- 8 CRT_B1 ---
9 GND --- 10 CRTHSYNC ---
11 CRTVSYNC --- 12 GND ---
13 CRTDCLK --- 14 CRTTDDAT ---
15 GND ---
CN14 FAN Connectors
PIN No. Signal name I/O PIN No. Signal name I/O
1 TH_FAN_POWER1 --- 2 GND ---
3 FANSIG1 O
CN48 Battery Connectors
PIN No. Signal name I/O PIN No. Signal name I/O
