Toshiba Strata CIX IPT User Manual

DKT/IPT Settings
IPT Setup Instructions
Strata CIX Telephones Administrator Manual 06/06 17
IPT Setup Instructions
1. Press 3+6+9+Hold (simultaneously).
2. Press
2, then press Hold to select the Network Setting Mode.
3. Press
FB1 to see if the DHCP server is in use or not. Press one of the following
(normally, use
1: manual setting):
1: manual setting, then press Hold.
2: auto setting by DHCP server, then press Hold.
4. Press
FB2. Enter the IP address for this IPT and press Hold. To enter the period in
an IP address, press the
*
button on your dialpad (e.g., if the IP address is
“192.168.1.241,” press
192
*
168
*
1
*
241).
5. Press
FB3. Enter the subnet mask number and press Hold. (e.g., if the subnet
mask address is “255.255.255.0, press
255
*
255
*
255
*
0).
6. If the IPT is connected to a router or other gateway device, press
FB4. Enter the
router address, then press
Hold. Only used if Step 3, above, is set for manual
setting.
7. Press
FB5. Enter a Station ID for the IPT and press Hold. This is usually your
telephone’s primary number (PDN).
8. Press
FB6 to enter the CIX Strata Net node number of the CIX node that contains
the LIPU to which this IPT interfaces, then press
Hold. This FB setting is for CIX
networked systems only.
9. Press
FB11 for LIPU address mode. Press one of the following:
1: manual setting, then press Hold. Press FB12 and enter the BIPU IP address,
then press
Hold. (e.g., if the LIPU address is “192.168.1.241,” enter it in this
format
192
*
168
*
1
*
241).
2: auto setting by broadcast, then press Hold.
3: auto setting by multicast (IPT doesn’t support multicast setting in this first
release), then press
Hold.
10. Press
Hold again to set all the above data.
11. Go off-hook and hang up. The IPT will search
for the LIPU, initialise and then set
the IP address (from 20 sec. to 60 sec.). Time, Date and PDN displays on LCD
when the information is set.
Note See “IP Telephone Start Up Sequence” below for an explanation of the LCDs
that you will see during this procedure.
