Notes to Users
Step 1: Safety Approval
52 Strata CIX Telephones Administrator Manual 06/06
SELV
PDKU2A/BDKU/BDKS/
BWDKU
For connection of Toshiba proprietary terminals.
SELV BSIS1A
For connection of Voice Mail and Call Logging
Equipment. RS232 ports.
TNV3
RSTU1F/RSTU3F/BSTU1F/
BSLU1F/BSLS1F/ASTU1F/
LSLU
For connection of Approved 2 wire devices.
TNV3
PCOU2F/PCOUS2FRCOU/
RCOS/RCOUS
For connection to PTO provided Loop Calling
Unguarded Clear exchange lines.
TNV1 RBSU1A/ RBSU2A
2 Cct ISDN2, (TBR3), Basic Rate I/F. For connection
to euro-ISDN services.
TNV1 RBSS1A & RBSS2A
2 Cct ISDN2, (TBR3), Basic Rate I/F. For connection
to approved Euro-ISDN services & devices.
TNV1 RPTU1F/RPTU2F/BPTU1F
1 ccts ISDN30, (TBR4), primary rate I/F. For
connection to euro-ISDN services..
TNV2 PACU2F/PACU3F
4 Cct AC15 Private Circuit I/F, (TBR17). For
connection to PTO Private Circuit services.
TNV2 PEMU2F/REMU
4 Cct DC5 Private Circuit I/F, (TBR 17). For
connection to PTO Private Circuit services.
SELV BIOU1A
Contains various ports for connection of audio
paging amplifiers, dry relay contacts to control
external equipment.
SELV
BVPU1A/BIPUM2A/
BIPQ1A/LIPU-X1A
Voice Over IP interface cards. House Ethernet/
RS232 ports
SELV
Stratagy DK, IES32,
GVMU1F
Integrated Voice Mail unit. Houses R232 ports.
SELV RRCU1A
Optical interface board for connecting remote
cabinets.
SELV BPCI1A USB port for connection of PC for CTI
SELV
DKT2500/DKT3000/
DKT3500/IPT1020/
DKT3200/IPT2000
Headset ports on any of the range of key telephones.
TNV3 LPFU1A
8 port power failure Transfer Unit for BSTU and
RCOU units.
TNV3 LCNU-C1A, LCNU-D1A Passive extender units for CIX product
Table A-1(continued)
Type of Circuit
(EN60950
Classification)
Port Location Port Description
