Step 4: Network Planning Information
60 Strata CIX Telephones Administrator Manual 06/06
Table A-4 below lists the various “typical” transmission gains/losses when inter-
connecting the various port types.
Table A-4
System Port
Type
RCOU3R/
PCOU2F
RBSU2A
RPTU1F/
RPTU2F
PEMU2F/
REMU
PACU2F/
PACU3F
RSTU3F
ASTU
-Values indicate a transmission loss.
4-3. Loudness Rating.
The table below lists the measured loudne
ss rating of the Toshiba proprietary
terminals.
SLR and RLR @ 0km PSTN. (All values are +/-dB)
Table A-5
System Port Type PDKU2A/BDKU/BDKS ITS-A
to fm to fm to fm to fm to fm to fm
PCOU2F/RCOU 3.7 3.7 1.8 1.9 1.8 1.9 3.1 3.2 -0.7 -1.5
RPTU1F/2F 1.91.80000
RBSU2A 1.91.80000
PEMU2F/REMU 3.1 3.2 1.3 1.3 1.3 1.3 2.6 2.6 -2.0 -2.0
PACU2F/PACU3F -0.7 -1.5 -3.4 -2.5 -3.4 -2.5 -2.0 -2.0 -6.0 -6.0
RSTU3F/ASTU -0.5 -1.0 -2.4 -2.8 -2.4 -2.8 -1.1 -1.5 -5.9 -6.2 -5.2 -5.2
SLR RLR
PCOU2F/RCOU3F 1dB -5dB to -16dB
RPTU1F/RPTU2F/RBSU1A 6dB 2dB to -10dB
PEMU2F/REMU 4dB -2dB to -14dB
PACU2F/PACU3F 8dB 0dB to -9dB
