10.5.5 Search of Coordinate Data [FIND]
(1) Function
Searches the data bearing the specified coordinate name.
(2) Procedures
Assume that you are going to search the coordinate data named
"TRANS00008."
(a) Step 1: Command selection.
Assume that the display is as following.
T R A N S S E L E C T I O N [ 1 / 1 1 ]
. w o r l d 1 0
T R A N S 0 0 0 0 1 0
T R A N S 0 0 0 0 2 5
T R A N S 0 0 0 0 3 0
↓
T R A N S 0 0 0 0 4 4
. w o r l d
E N D F U L L F I N D W O R K T O O L
Press [FIND], and the following display appears.
T R A N S S E L E C T I O N [ 1 / 1 1 ]
. w o r l d 1 0
T R A N S 0 0 0 0 1 0
T R A N S 0 0 0 0 2 5
T R A N S 0 0 0 0 3 0
↓
T R A N S 0 0 0 0 4 4
F I N D : _
(b) Step 2: Data name input.
Enter "TRANS00008", and the display is changed over as shown below.
T R A N S S E L E C T I O N [ 1 / 1 1 ]
. w o r l d 1 0
T R A N S 0 0 0 0 1 0
T R A N S 0 0 0 0 2 5
T R A N S 0 0 0 0 3 0
↓
T R A N S 0 0 0 0 4 4
F I N D : T R A N S 0 0 0 0 8 _
