Archer C3200 AC3200 Wireless Tri-Band Gigabit Router
4) Enter a connection name for your IPSec VPN.
5) Enter Site B’s WAN IP address.
6) For Site A’s whole LAN here we select Subnet Address. Then input the
LAN IP range and Subnet Mask of Site A.
7) For Site B’s whole LAN here we select Subnet Address. Then input the
LAN IP range and Subnet Mask of Site B.
8) Select the Key Exchange Method for the policy. We select Auto(IKE)
here.
9) Enter the Pre-shared Key for IKE authentication. Then keep Perfect
Forward Secrecy enabled.
Note:
i. The key should consist of visible characters without blank space.
ii. Make sure Site A and Site B use the same key.
10) Leave the Advanced Settings as default value. Then click OK to save.
3. Configuration on Site B (remote network). You can do refer to step 2. Make
sure that Site A and Site B use the same pre-shared keys and Perfect
Forward Secrecy settings.
4. The Status column will change to UP if the VPN connection has been set
up successfully.
5. Check the VPN connection. You can ping site B' LAN IP from your computer
to verify that the IPSec VPN connection is set up correctly.
*To check the VPN connection, you can do the following:
1) On the host in Site A, press [Windows Logo] + [R] to open Run dialog.
Input “cmd” and hit OK.
- 83 -
