150Mbps Wireless AP/Client Router User Guide
72
Figure 4-59
2. Click the Browse button, and then select the Select Volume from the drop-down list.
3. Enter display name of the share folder in Share Name filed.
4. Click the Apply button to apply the settings.
You can click the upper button to go to the upper folder
Click the Enable/Disable Selected button to enable or disable the selected entries.
Click the Delete Selected button to delete the selected entries.
)
Note:
1. The max share folders number is 10. If you want to share a new folder when the number has
reached 10, you can delete an existing share folder and then add a new one.
2. If you want to change the Storage Sharing settings, you can click the Apply button to make
the changes take effect.
4.8.4 FTP Server
Choose menu “USB SettingsFTP Server”, you can create an FTP server that can be
accessed from the Internet or your local network.

Table of Contents

Other manuals for TP-Link TD-VG3631

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link TD-VG3631 and is the answer not in the manual?

TP-Link TD-VG3631 Specifications

General IconGeneral
VPN supportPPTP, L2TP, IPSec
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)300 Mbit/s
Input current1.5 A
Input voltage12 V
Rack mountingNo
Frequency band2.4 GHz
USB ports quantity2
Management platformHTTP/Telnet/CLI/SNMP/SSL
Filtering descriptionMAC / IP / Packet / URL
Compatible operating systemsWindows 98SE, NT, 2000, XP, Vista, 7\\r MAC OS\\r NetWare, UNIX, Linux
Ethernet LAN (RJ-45) ports4
DHCP client-
Routing protocolsRIP-1, RIP-2
Antenna connector typeRP-SMA
Antenna gain level (max)5 dBi
Security algorithms128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
CertificationCE, FCC, RoHS
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Cables includedLAN (RJ-45), Phone (RJ-11)
Weight and Dimensions IconWeight and Dimensions
Depth177 mm
Width256 mm
Height51 mm
