TPS smartCHEM-Titro - DC Switched Output

18
3. Press to begin the Standard Titration. The smartCHEM-Titro will refill the burette
and start the titration. For example…
4.00pH 25.0
o
C
0.00mL 12:01:00
Titrating to
7.00pH
4. The smartCHEM-Titro will display a prompt when the titration is complete. For example…
7.00pH 25.0
o
C
10.00mL 12:05:00
Titration complete.
Press Print or Enter
5. Press to send the result to the serial port, which can be connected to a PC or an RS232
compatible printer. Press to exit and return to the opening screen.
3.5 12V DC Switched Output (Optional)
When the smartCHEM-Titro is in Standard Titrator mode, the 12V DC output can be activated
manually to switch on devices such as a solenoid valve for degassing. This function is available at
any time. A 1 Amp AC/DC adaptor is required when using the optional solenoid valve.
Press when the unit is in its main display to switch the 12V output ON. A “ * ” is shown in the
display to provide visual indication, for example…
11.00pH 25.0
o
C
0.00mL* 12:00:00
Press F6 to start
STD Titration
Press again to switch the 12V output OFF.
