12.5 Printing Records from the Logger to the RS232 Port
1. Connect one end of the RS232 cable to the Power/RS232 socket of the smartCHEM-Titro.
2. Connect the other end of the RS232 cable to an RS232 Printer, or to a Serial port of a PC.
3. Ensure that the baud rate for the printer or PC and the smartCHEM-Titro are the same. If
necessary, alter the baud rate of the smartCHEM-Titro (see section 13.1).
The smartCHEM-Titro uses XON/XOFF protocol. Ensure that the printer is set accordingly.
4. Select the Logger menu. ( →
→→
→ F2:Logger ).
5. Select F3:Print from the menu.
6. Printing starts as soon as is pressed. The display shows the word “ Printing ” until
printing is completed.
