1. Introduction
1.1 smartCHEM-Titro Display and Controls
1.2 smartCHEM-Titro Rear Panel Connectors
Turn the retaining nut clockwise until it clicks into place when plugging in plastic
connectors. This is essential to produce a waterproof seal.
Always replace the waterproof cap when a connector is not in use to maintain
waterproof integrity.
Function
and Menu
Keys
One-Touch
and Enter
Keys
Numeric
Keypad
240 x 64 dot Graphic LCD with Backlight
On / Off
Switch
12V DC Power
Input and
RS232 Port
Temperature
Sensor
Karl Fischer Polarisation
Titration
Burette
Reference Sensor
pH/mV/Ion Sensor
