1.3 Function and Menu Keys
Press to enter the user-friendly menu system. is also used to step backwards through the
menu one level at a time, and as an “escape” key to quit functions such as calibration, data entry etc.
Press the to function keys to select desired options within the menu system.
Additionally, these keys perform the following function directly in normal measurement mode…
: Press to start the Automatic Titration (section 3.4).
: Press to start and stop the Automatic Stability Function. See section 8.
1.4 One-Touch Keys
: Press to manually record readings into the Logger. See section 12.1.
: Press to transmit current reading plus date and time to the RS232 port. See section 13.2.
: Press to start and stop Automatic Datalogging. See section 12.2.
: Press to accept default values or those entered on the Numeric Keypad.
1.5 Numeric Keypad
Used to enter values during set-up and calibration. A decimal point is provided.
1.6 Delete Key
Press to make corrections to values entered on the Numeric Keypad.
1.7 240 x 64 Dot Graphic Display
Graphic display with large, clear digits and letters. Features a user-friendly menu and context-
sensitive help system. pH/mV/Relative mV, Temperature, Dosed mL and Time simultaneously.
Backlight can be set to On, Off or Energy Saver modes. See section 9.
