148
Troubleshooting Drive
System
Troubleshooting Brake
System
Problem: Power not transmitted from engine to wheels
Condition Remedy
1. Rear axle shaft serration worn — broken 1. Replace shaft
Problem: Power not transmitted from engine to either front wheel
Condition Remedy
1. Secondary drive - driven gear teeth broken
2. Propeller shaft serration worn — broken
3. Coupling damaged
4. Coupling joint serration worn — damaged
5. Front drive — driven bevel gears broken — damaged
6. Front differential gears/pinions broken — damaged
7. Front drive actuator not operating
1. Replace gear(s)
2. Replace shaft
3. Replace coupling
4. Replace joint
5. Replace gear(s)
6. Replace gears — pinions
7. Replace fuse — drive select switch — front drive actuator
Problem: Braking poor
Condition Remedy
1. Pad worn
2. Brake fluid leaking
3. Master cylinder/brake cylinder seal worn
1. Replace pads
2. Repair — replace hydraulic system
3. Replace seal(s)
Problem: Brake pedal travel excessive
Condition Remedy
1. Brake fluid low
2. Piston seal — cup worn
1. Add fluid to proper level
2. Replace seal — cup
Problem: Brake fluid leaking
Condition Remedy
1. Connection fittings loose
2. Hose cracked
3. Piston seal worn
1. Tighten fittings
2. Replace hose
3. Replace seal
Problem: Brake pedal spongy
Condition Remedy
1. Air trapped in hydraulic system
2. Brake fluid low
1. Bleed hydraulic system
2. Add brake fluid and bleed hydraulic brake system
