38
PK064A
4. Remove the taillight/brake light socket by rotating
the socket counterclockwise. Rotate the bulb coun-
terclockwise to remove from socket.
PK328
INSPECTING
1. Inspect wiring harness, three-prong connector, lens,
base, cap screws, and socket for damage.
2. Inspect all wires for corroding, pinching, and cracking.
3. Inspect the bulb for wattage, voltage, and proper
operation.
INSTALLING
1. Place the rear fender onto the cargo box and secure
with the six plastic screws. Secure the tie-down with
the two nuts and cap screws.
2. Connect the taillight/brake light connector.
Seat
REMOVING/INSTALLING
1. To remove the seat, raise the front of the seat and
slide it forward.
2. To install the seat, slide the rear of the seat into the seat
retainers and push down firmly on the front of seat.
