11
11
Physical Features
Bar Mounting:
Place nuts and bolts
as shown in picture.
Temperature Sensors:
Please see-model-specific
instructions for mounting procedure.
Cylinder Head Temperature
Sensor for air-cooled machines.
Temperature Sensor
in-line in radiator hose for
water-cooled machines.
TEMP.
SENSOR
RADIATOR
HOSE
SPARK
PLUG
