15
Physical Features
Motorcycle Sensor/Magnet Installation:
Motorcycles, like ATVs,
need a magnet placed
on the spinning part
of the wheel and the
sensor installed to a non-
spinning part.
The magnet typically gets
bolted or glued to the
brake rotor. The speed
sensor wire should come
from the back of the
computer, be cable-tied to the brake line as it travels down the front
forks, then attached to the brake caliper.
Striker can tell how far and fast
it’s traveled by how many times
the magnet passes the sensor.
Many Motorcycles and ATVs
have special installation
procedures. Refer to the
provided installation insert for
model-specific instructions.
Optimum Magnet Rotation Path
Magnet About to Pass Under Sensor
