Physical Features
There are two screw holes on
the back of Striker. Use the
included M4 bolts to mount to
any flat surface.
If other than provided screws
are used, make sure they are
not too long for mounting holes.
Screws that are too long will
damage internal
components of Striker.
Flat/Surface Mount:
DRILL TEMPLATE
SCALE 1:1
Drill Size:
• 4.2mm
• 0.165”
107.5mm
40mm
59.5mm
Mounting
Hole
Accepts
M4 Bolts
