Trane Pivot Smart User Manual

BAS-SVU044D-EN
13
Thermostat Home Screen
The features and functions of the thermostat Home screen are described in
the following figure. The Menu screen and the Settings screen are described
in subsequent sections.
Figure 2. Thermostat interface home screen (icons and functions)
Network
Status
Tap to change fan modes
(Auto/or On)
Tap to change system modes
(Auto/Heat/Cool/O/Emergency
Heat)
Tap for additional menu screens
Current space
temperature
Occupancy mode
icon (Occupied
shown)
Tap to increase the
Cooling or Heating
temperature setpoint
Tap to allow changing
the Cooling temperature
setpoint
Tap to allow changing
the Heating temperature
setpoint
Tap to decrease the
Cooling or Heating
temperature setpoint
Weather
display
(optional)

Trane Pivot Smart Specifications

General

Brand	Trane
Model	Pivot Smart
Category	Thermostat
Language	English
