24
BAS-SVU044D-EN
• If the thermostat is in Unoccupied mode, tap the occupancy mode icon to
change the mode and setpoints to Occupied. The thermostat will
continue to use the occupied setpoints until manually changed by a user.
• If the thermostat is in Occupied mode, tap the occupancy mode icon to
change the mode and setpoints to unoccupied. The thermostat will
continue to use the unoccupied setpoints until manually changed by a
user.
Setting Up Temporary Setpoint Adjustments
NNoottee:: Temperature adjustments (overrides) are only available when the
thermostat is in occupied mode or if the schedule is disabled.
The following figure illustrates how to temporarily override a temperature
setpoint when in occupied mode.
Figure 9. Screen showing a temperature override
Tap to allow changing the
Cooling temperature
setpoint
Tap to allow changing the
Heating temperature setpoint
Tap to decrease the Cooling or
Heating temperature setpoint
Occupancy mode icon
(Occupied Shown
)
Tap to increase the Cooling
or Heating temperature
setpoint
The temperature override will remain in effect until the next occupancy
mode change, or a predetermined amount of time, depending on how the
temperature override expiration has been set up. See “Setting Up a
Temperature Override Expiration,” p. 24.
Setting Up a Temperature Override Expiration
TToo sseett uupp aa tteemmppeerraattuurree oovveerrrriiddee eexxppiirraattiioonn:
1. Navigate to HHoommee >> MMeennuu >> SScchheedduullee SSeettppooiinnttss >> OOvveerrrriiddee
EExxppiirraattiioonn (see Figure 10, p. 25).
2. Select how the Temperature override will be configured:
• MMooddee (tap to set the override to expire at the next occupancy mode
change).
SSeettppooiinntt AAddjjuussttmmeenntt
