Specifications
Specification Description Specification Description
Touch Screen
Display
4.15 inches x 2.65
inches (4.3 inches
diagonal)
Auxiliary Heat
Lockout
32°F to 70°F
Configurations
• Heat/cool
• Dual fuel
• Heat only
• Cooling only
• Heat pump
Compressor Heat
Lockout
5°F to 70°F
Maximum Number
of Stages
• Conventional:
Three heat/two
cool
• Heat pump:
Two
compressors,
three auxiliary
heat
Cooling Setpoint
Temperature Range
60°F to 99°F, 1°F
resolution
Storage/Operating
Temperatures
-40°F to 175°F, 5%
to 95% RH non-
condensing
Heating Setpoint
Temperature Range
55°F to 99°F, 1°F
resolution
Input Power
24 Vac
Indoor
Temperature
Display Range
-40°F to 122°F
Power
Consumption
3 VA typical, 7 VA
maximum
Outdoor
Temperature
Display Range
-40°F to 140°F
Wire Usage
18 AWG (300 ft
maximum for
remote sensors)
Indoor Humidity
Display Range
0% to 100%, 1%
resolution
System Modes
• Auto
• Heating
• Cooling
• Off
Minimum Cycle Off
Time
• Compressor; 5
minutes
• Indoor Heat; 1
minute
Fan Modes
• Auto
• On
Mobile App
operating system
Android and iOS
