PKG-SVX027D-EN
21
Figure 8. Discharge opening for 25 ton
560
22.05
OPENING
WIDTH DISCHARGE
736
28.99
DEPTH DISCHARGE
OPENING
AIR FLOW
Figure 9. Discharge opening for 30 and 35 ton
OPENING
DEPTH DISCHARGE
736
28.99
880
34.64
WIDTH DISCHARGE
OPENING
AIR FLOW
