PKG-SVX027D-EN
55
Table 17. Points list
Hardware Connection Point Name
Point Setup
UC600
PI
Supply Duct Static Pressure Sensor Honeywell Pressure Sensor
BO1 — —
BO2 — —
BO3 — —
BO4 — —
AO1/UI9 Water Side Economizer
2 Vdc = 0%, 10 Vdc = 100%
AO2/UI10
High Duct Temp Cutout (Optional) Open = Tripped, Closed = Normal
AO3/UI11
Compressor 1 Speed Command 1.7 Vdc = Min Speed, 10 Vdc = Max Speed
AO4/UI12
Compressor 1 High Pressure Cutout Open = Alarm, Closed = Normal
AO5/UI13
Compressor 2 High Pressure Cutout Open = Alarm, Closed = Normal
AO6/UI14
Compressor 2 Safety Circuit Stauts Open = Circuit Open, Closed = Circuit Complete
UI1
Compressor 3 High Pressure Cutout Open = Alarm, Closed = Normal
UI2
Compressor 3 Safety Circuit Status Open = Circuit Open, Closed = Circuit Complete
UI3
Discharge Air Temperature Local 10K Ohm Resistor Trane Type 2
UI4
Entering Air Temperature Local 10K Ohm Resistor Trane Type 2
UI5 ESTOP
Open = Normal, Closed = Emergency Stop
UI6
Exterior Auto/Stop Open = Auto, Closed = Exterior Stop
UI7
Compressor 1 Status Open = Off, Closed = Runing
UI8
Occupancy Input Open = Unoccupied, Closed = Occupied
XM70.1
PI Air Filter Differential Pressure
Honeywell Pressure Sensor
BO1
Heat Output 1 Open = Off, Closed = On
BO2
Heat Output 2 Open = Off, Closed = On
BO3
Heat Output 3 Open = Off, Closed = On
BO4 — —
AO1/UI9
Supply Fan 1 Speed Command
0 Vdc = 0%, 10 Vdc = 100%
AO2/UI10
Supply Fan 2 Speed Command
0 Vdc = 0%, 10 Vdc = 100%
AO3/UI11
Supply Fan 3 Speed Command
0 Vdc = 0%, 10 Vdc = 100%
AO4/UI12
Supply Fan 4 Speed Command
0 Vdc = 0%, 10 Vdc = 100%
AO5/UI13
Morning Warmup Input Open = Off, Closed = Morning Warmup
AO6/UI14
Heating Output 1 Command 2 Vdc = 100% Open, 10 Vdc = 0% Open
UI1
Supply Fan 1 VFD Fault Open = Normal, Closed = Fault
UI2
Supply Fan 2 VFD Fault Open = Normal, Closed = Fault
UI3
Supply Fan 3 VFD Fault Open = Normal, Closed = Fault
UI4
Supply Fan 4 VFD Fault Open = Normal, Closed = Fault
UI5
Space Temperature Local 10K Ohm Resistor Trane Type 2
UI6 — —
UI7
Compressor 1 VFD Fault Open = Normal, Closed = Alarm
UI8 Condenser Water Flow Switch
Open = No Flow, Closed = Flow
XM32.2
BO1
Supply Fan 1 Start Stop Command NO Open = Stop, NO Closed = Run; NC not used
BO2
Supply Fan 2 Start Stop Command NO Open = Stop, NO Closed = Run; NC not used
BO3
Supply Fan 3 Start Stop Command NO Open = Stop, NO Closed = Run; NC not used
BO4
Supply Fan 4 Start Stop Command NO Open = Stop, NO Closed = Run; NC not used
