100 RT-PRC024-EN
Weights
(12½-25 Tons)
Table 85. Accessory Net Weights (Lbs)
(i)
,
(ii)
(i)
Net weight should be added to unit weight when ordering factory installed accessories.
(ii)
TC*150-300 factory installed options for economizers, multiply net capacity x .99, EER x .97. For oversized motors, multiply net capacity x .98,
EER x .93. This is provided in compliance with ARI certification program.
Unit Economizer Outside Air Damper Power Roof Oversized High Static Low Static LPG
Model No. Net Manual Motorized Exhaust
(iii)
(iii)
Downflow only.
Curb
(iv)
(iv)
Downflow only.
Motor Adder Drive
(v)
(v)
Not available on all models (See Fan Performance tables for specific models).
Drive
(vi)
(vi)
Not available on all models (See Fan Performance tables for specific models).
Conversion Kit
T/YCD150D,180B
T/YCD151C, TCD210C 65 32 60 95 205 5 2 2 5
T/YCD240B
T/YCD181,211,241C 80 32 75 95 235 5 2 — 5
T/YCD300B,301C 80 32 75 95 235 N/A N/A 2 5
T/YCH150D, 180B, 210C
T/YCH151C 50 32 60 — — 5 2 2 5
T/YCH240B
T/YCH181,211,241C 65 32 75 — — 5 2 — 5
T/YCH300B,301C 65 32 75 — — N/A N/A 2 5
Table 86. (continued) Accessory Net Weights (Lbs)
Electric Heaters
Unit All 6-23 kW 27-36 kW 54 kW 72 kW
Model No. Zone Sensors 240/480V
(i)
,
(ii)
(i)
For 600V heaters net weights are same as 480V heaters.
(ii)
To estimate shipping weight add 5 lbs to net weight.
240/480V
(iii)
,
(iv)
(iii)
For 600V heaters net weights are same as 480V heaters.
(iv)
To estimate shipping weight add 5 lbs to net weight.
240/480V
(v)
,
(vi)
(v)
For 600V heaters net weights are same as 480V heaters.
(vi)
To estimate shipping weight add 5 lbs to net weight.
240/480V
(vii)
,
(viii)
(vii)
For 600V heaters net weights are same as 480V heaters.
(viii)
To estimate shipping weight add 5 lbs to net weight.
T/YCD150D, 180B, 210C 1 28/21
(ix)
(ix)
9 - 23 KW Heaters not available for TC*210C.
31/27 38/32 —
T/YCD151,181C
T/YCD240B 1 — 33/27 40/32 43/34
T/YCD211,241C
T/YCD300B,301C 1 — 33/27 40/32 43/34
T/YCH150D, 180B, 210C 1 28/21
(x)
(x)
9 - 23 KW Heaters not available for TC*210C.
31/27 38/32 —
T/YCH151,181C
T/YCH240B 1 — 33/27 40/32 43/34
T/YCH211, 241C
T/YCH300B, 301C 1 — 33/27 40/32 43/34
To Next Page
