98 RT-PRC024-EN
Dimensional Data
Table 82. Power Exhaust Dimensions
Figure 22. Economizer - Horizontal Units
Note: When applying economizer to horizontal units, connected
ductwork must be run full size to allow proper operation of
economizer damper.
Figure 23. Economizer - Downflow Units
Figure 24. Power Exhaust - Downflow
Economizers - Side View
Unit
Model # A B
(i)
(i)
Horizontal dimension only. Downflow economizer is width of
end panel.
C
(ii)
(ii)
Power exhaust is applied on downflow economizer only.
T/YC*150-151-180,210 17½ 53¾ 36
T/YC*181, 211-301 19½ 64¾ 39
C
POWER EXHAUST with DOWNFLOW
ECONOMIZERS only, SIDE VIEW
(12½-25 Tons Accessories)
Figure 19. Fresh Air Hood (Horizontal Units)
Figure 20. Fresh Air Hood (Downflow Units)
Figure 21. Power Exhaust - Downflow
Economizers
19 ½”
FRESH AIR HOOD (MANUAL)
HORIZONTAL UNITS
495 MM
