Electrical Data
(High Efficiency)
Table 69. Unit Wiring with Electric Heat (Single Point Connection) — Standard Refrigeration System (Downflow and Horizontal)
Standard Indoor Motor Oversize Indoor Motor
Tons
Unit Model
Number
Heater Model
Number
Heater kW
Rating
Control
Stages MCA
Max Fuse Size
or Max Circuit
Breaker MCA
Max Fuse Size
or Max Circuit
Breaker
(i)
(i)
Values do not include power exhaust accessory.
* Indicates both downflow and horizontal units.
208/230 Volts Three Phase
12½ TC*151C3 AYDHTRK318A/AYHHTRN318A 13.5/18.0 1 64/68 80/80 70/76 90/90
AYDHTRK336A/AYHHTRP336A 27.0/36.0 2 108/122 110/125 115/130 125/150
AYDHTRK354A/AYHHTRP354A 40.5/54.0 2 154/176 175/200 162/184 175/200
15 TC*181C3 AYDHTRK318A/AYHHTRM318A 13.5/18.0 1 74/74 100/100 80/80 100/100
AYDHTRK336A/AYHHTRM336A 27.0/36.0 2 108/122 110/125 115/130 125/150
AYDHTRK354A/AYHHTRM354A 40.5/54.0 2 154/176 175/200 162/184 175/200
17½ TC*211C3 AYDHTRL336A/AYHHTRN336A 27.0/36.0 2 115/130 125/150 125/139 125/150
AYDHTRL354A/AYHHTRN354A 40.5/54.0 2 162/184 175/200 171/193 175/200
AYDHTRK372A/AYHHTRN372A 54.0/72.0 2 209/238 225/250 218/247 225/250
20 TC*241C3 AYDHTRL336A/AYHHTRN336A 27.0/36.0 2 115/130 125/150 125/139 125/150
AYDHTRL354A/AYHHTRN354A 40.5/54.0 2 162/184 175/200 171/193 175/200
AYDHTRK372A/AYHHTRN372A 54.0/72.0 2 209/238 225/250 218/247 225/250
25 TC*301C3 AYDHTRL336A/AYHHTRN336A 27.0/36.0 2 125/139 150/150 — —
AYDHTRL354A/AYHHTRN354A 40.5/54.0 2 171/193 175/200 — —
AYDHTRK372A/AYHHTRN372A 54.0/72.0 2 218/247 225/250 — —
460 Volts Three Phase
12½ TC*151C4 AYDHTRL418A/AYHHTRN418A 18.0 1 34 40 37 40
AYDHTRK436A/AYHHTRP436A 36.0 2 61 70 64 70
AYDHTRK454A/AYHHTRP454A 54.0 2 88 90 91 100
15 TC*181C4 AYDHTRL418A/AYHHTRM418A 18.0 1 36 50 38 50
TCD181C4 AYDHTRK427A 27.0 2 47 50 — —
TC*181C4 AYDHTRK436A/AYHHTRM436A 36.0 2 61 70 64 70
AYDHTRK454A/AYHHTRM454A 54.0 2 88 90 91 100
17½ TCD211C4 AYDHTRL427A 27.0 2 51 60 — —
TC*211C4 AYDHTRL436A/AYHHTRN436A 36.0 2 64 70 68 70
AYDHTRL454A/AYHHTRN454A 54.0 2 91 100 95 100
AYDHTRK472A/AYHHTRN472A 72.0 2 118 125 123 125
20 TCD241C4 AYDHTRL427A 27.0 2 51 60 — —
TC*241C4 AYDHTRL436A/AYHHTRN436A 36.0 2 64 70 68 70
AYDHTRL454A/AYHHTRN454A 54.0 2 91 100 95 100
AYDHTRK472A/AYHHTRN472A 72.0 2 118 125 123 125
25 TCD301C4 AYDHTRL427A 27.0 2 58 70 — —
TC*301C4 AYDHTRL436A/AYHHTRN436A 36.0 2 68 70 — —
AYDHTRL454A/AYHHTRN454A 54.0 2 95 100 — —
AYDHTRK472A/AYHHTRN472A 72.0 2 123 125 — —
575 Volts Three Phase
12½ TC*151CW AYDHTRKW18A/AYHHTRNW18A 18.0 1 27 30 30 35
AYDHTRMW36A/AYHHTRPW36A 36.0 2 49 50 51 60
AYDHTRKW54A/AYHHTRPW54A54.02707073 80
15 TC*181CW AYDHTRKW18A/AYHHTRMW18A 18.0 1 29 40 31 40
AYDHTRMW36A/AYHHTRMW36A 36.0 2 49 50 31 40
AYDHTRKW54A/AYHHTRMW54A 54.0 2 70 70 73 80
17½ TC*211CW AYDHTRMW36A/AYHHTRMW36A 36.0 2 51 60 55 60
AYDHTRLW54A/AYHHTRNW54A 54.0 2 73 80 77 80
AYDHTRKW72A/AYHHTRNW72A 72.0 2 95 100 98 100
20 TC*241CW AYDHTRMW36A/AYHHTRMW36A 36.0 2 51 60 55 60
AYDHTRLW54A/AYHHTRNW54A 54.0 2 73 80 77 80
AYDHTRKW72A/AYHHTRNW72A 72.0 2 95 100 98 100
25 TC*301CW AYDHTRMW36A/AYHHTRMW36A 36.0 2 55 60 — —
AYDHTRLW54A/AYHHTRNW54A 54.0 2 77 80 — —
AYDHTRKW72A/AYHHTRNW72A 72.0 2 98 100 — —
