52 RT-PRC024-EN
Performance Data
(12½ Tons High Efficiency)
Table 34. Evaporator Fan Performance 12½ Tons TCH151C Standard Refrigeration System Horizontal
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3-HP Standard Motor & Field Supplied Low Static Drive
(i)
(i)
Field Supplied Fan Sheave BK115 Required. Field Supplied Belt may be necessary.
3-HP Standard Motor & Drive
4000 — — — — 510 0.98 541 1.10 572 1.22 602 1.35 631 1.48 659 1.62 687 1.76 714 1.91
4500 — — 521 1.17 551 1.29 579 1.42 607 1.56 635 1.68 662 1.82 688 1.98 713 2.13 738 2.28
5000 534 1.40 566 1.54 593 1.67 620 1.81 645 1.95 671 2.11 696 2.25 720 2.40 744 2.56 767 2.73
5500 581 1.83 611 1.99 637 2.13 661 2.28 685 2.43 709 2.59 732 2.76 754 2.92 777 3.08 799 3.25
6000 628 2.34 657 2.51 682 2.68 704 2.83 727 3.00 749 3.16 770 3.33 791 3.52 812 3.70 833 3.87
5-HP Oversized Motor & Drive
Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3-HP Standard Motor & Drive 3-HP Standard Motor & High Static Drive Accessory
4000 740 2.07 766 2.23 791 2.38 814 2.54 838 2.70 860 2.86 883 3.02 905 3.19 926 3.37 948 3.55
4500 763 2.44 787 2.61 811 2.78 835 2.96 858 3.13 880 3.31 901 3.48 922 3.66 943 3.84 963 4.02
5000 790 2.90 812 3.07 835 3.24 857 3.42 879 3.61 901 3.81 922 4.00 942 4.20 962 4.39 982 4.59
5500 820 3.43 842 3.61 862 3.80 883 3.98 904 4.17 924 4.37 944 4.57 964 4.78 984 4.99 1003 5.20
6000 853 4.04 874 4.23 893 4.43 913 4.63 932 4.83 951 5.03 970 5.24 988 5.45 1007 5.66 — —
5-HP Oversized Motor & Drive
For Standard Evaporator Fan Speed (RPM), reference Table 50.
For Standard Motor & Low Static Drive Accessory Fan Speed (RPM), reference Table 51.
For Oversized Evaporator Fan Speed (RPM), reference Table 53.
Fan motor heat (MBH) = 3.15 x Fan BHP.
Notes:
Data includes pressure drop due to standard filters and wet coils. No accessories or options are included in pressure drop data.
Refer to Table 54 to determine additional static pressure drop due to other options/accessories.
Factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all
cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product's warranty will not be affected.
