RT-PRC024-EN 45
Performance Data
(17½ Tons Standard Efficiency)
Table 27. Evaporator Fan Performance 17½ Tons with Gas Heat YC*210C Downflow or Horizontal
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5-HP Standard Motor & Low Static Drive Accessory 5-HP Standard Motor & Drive
5600 — — 720 2.27 744 2.39 767 2.51 791 2.65 815 2.79 838 2.93 860 3.08 883 3.23 906 3.39
6300 776 3.02 798 3.16 820 3.29 841 3.42 862 3.56 883 3.72 905 3.88 926 4.04 946 4.20 965 4.36
7000 857 4.11 878 4.26 898 4.41 917 4.56 935 4.70 954 4.86 974 5.03 993 5.21 1013 5.39 1031 5.57
7700 939 5.44 958 5.60 976 5.77 994 5.93 1011 6.09 1028 6.25 1045 6.42 1062 6.60 1080 6.79 1098 6.99
8400 1021 7.03 1038 7.21 1055 7.39 1072 7.57 1088 7.74 1104 7.92 1119 8.09 1135 8.27 1151 8.46 — —
7.5-HP Oversized Motor & Drive
Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5-HP Standard Motor & Drive
5600 929 3.55 951 3.72 974 3.90 996 4.08 1018 4.27 1039 4.45 1060 4.62 1082 4.81 1105 5.01 1127 5.22
6300 984 4.53 1005 4.70 1026 4.88 1047 5.07 1067 5.27 1087 5.46 1106 5.66 1125 5.86 1145 6.07 1164 6.27
7000 1049 5.74 1066 5.92 1084 6.11 1102 6.30 1121 6.49 1139 6.69 1159 6.90 1176 7.11 1194 7.33 1212 7.55
7700 1116 7.20 1132 7.39 1149 7.59 1164 7.78 1180 7.98 1197 8.18 1213 8.39 1230 8.60 — — — —
8400 — — — — — — — — — — — — — — — — — — — —
7.5-HP Oversized Motor & Drive
For Standard Evaporator Fan Speed (RPM), reference Table 50
For Standard Motor & Low Static Drive Accessory Fan Speed (RPM), reference Table 51.
For Oversized Evaporator Fan Speed (RPM), reference Table 53.
Fan motor heat (MBH) = 3.15 x Fan BHP.
Notes:
Data includes pressure drop due to standard filters and wet coils. No accessories or options are included in pressure drop data.
Refer to Table 54 to determine additional static pressure drop due to other options/accessories.
Factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all
cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product's warranty will not be affected.
*For 380V/60 Hz units, the oversized motor is used as the standard motor. Refer to "Motor & Sheave/Fan Speed" tables to determine operating range.
