14 RT-PRC024-EN
DIGIT 9,10 — FACTORY INSTALLED
OPTIONS
Note: (Applicable to Digit 1, 2
T models only)
00 No Factory-installed Options
0A Factory-installed Economizer
0B Oversized Motor
0C Downflow Economizer and
Oversized Motor
0F Trane Communications
Interface (TCI)
0G Downflow Economizer and
TCI
0H TXV/Face-Split Evaporator
0J Oversized Motor and TXV
Face-Split Evaporator
0K Downflow Economizer,
Oversized Motor, and TXV
Face-Split Evaporator
0L Downflow Economizer with
TXV/Face-Split Evaporator
0M Reheat Coil
0N Downflow Economizer and
Reheat Coil
0P Oversized Motor and Reheat
Coil
0R Downflow Economizer,
Oversized Motor and Reheat
Coil
DIGIT 9 — HEATING CAPACITY
Note: (Applicable to Digit 1, 2
Y models only)
LLow Heat
M Medium Heat
H High Heat
DIGIT 1,2 — UNIT TYPE
TC Packaged Cooling, Electric
Heat
TF With Factory Installed
Options
YC Packaged Gas/Electric
YF With Factory Installed
Options
DIGIT 3 — AIRFLOW
CONFIGURATION
DDownflow
H Horizontal
DIGIT 4,5,6 — NOMINAL GROSS
COOLING CAPACITY (MBh)
150 12½ Tons Standard Efficiency
151 12½ Tons High Efficiency
180 15 Tons Standard Efficiency
181 15 Tons High Efficiency
210 17½ Tons Standard Efficiency
211 17½ Tons High Efficiency
240 20 Tons Standard Efficiency
241 20 Tons High Efficiency
300 25 Tons Standard Efficiency
301 25 Tons High Efficiency
DIGIT 7 — MAJOR DESIGN
SEQUENCE
DIGIT 8 — VOLTAGE SELECTION
3 208-230/60/3
4 460/60/3
W 575/60/3
K 380/60/3
T C D 150 C 3 0 0 A A
1 2 3 456 7 8 9 10 11 12
DIGIT 10 — FACTORY INSTALLED
OPTIONS
17
Note: (Applicable to Digit 1, 2
Y models only)
0 Packed Stock, No Options
A Downflow Economizer
1
B Oversized Motor
7
C Downflow Economizer and
Oversized Motor
1
F Trane Communications Interface
(TCI)
2,7
G Downflow Economizer and TCI
1,2
H TXV/Face-Split Evaporator
16
J Oversized Motor and TXV/Face
Split Evaporator
16
K Downflow Economizer,
Oversized Motor, and TXV/Face
Split Evaporator
1,16
L Downflow Economizer with TXV
Face-Split Evaporator
7,16
M Reheat Coil
3,16
N Downflow Economizer and
Reheat Coil
1,3,16
P Oversized Motor and Reheat
Coil
1,3,16
R Downflow Economizer,
Oversized Motor and Reheat
Coil
1,3,16
DIGIT 11 — MINOR DESIGN
SEQUENCE
DIGIT 12 — SERVICE SEQUENCE
Note: Explanation of Model
Number Notes located on the
following page.
Note: Some Factory Installed
Options (FIOPS) available for
Downflow Air Discharge
units only. Please verify with
ordering system for
availability.
Model Number Description
