40 RT-PRC024-EN
Table 22. Evaporator Fan Performance 12½ Tons TC*150D Downflow or Horizontal
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3-HP Standard Motor & Field Supplied Low Static Drive
(i)
(i)
Field Supplied Fan Sheave BK90 required. Field Supplied Belt may be necessary.
3-HP Standard Motor & Sheaves
4000 — — — — — — 565 0.93 599 1.03 632 1.15 663 1.27 695 1.38 727 1.48 757 1.59
4500 — — — — 571 1.10 603 1.21 634 1.31 665 1.43 694 1.56 723 1.69 750 1.82 778 1.94
5000 547 1.18 581 1.30 613 1.42 643 1.54 672 1.67 700 1.78 727 1.91 755 2.05 781 2.19 806 2.34
5500 595 1.55 627 1.68 656 1.81 685 1.94 711 2.08 737 2.21 763 2.34 788 2.47 813 2.62 837 2.77
6000 643 1.99 673 2.12 701 2.26 727 2.41 752 2.56 777 2.71 801 2.85 825 2.99 848 3.13 871 3.27
Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & Sheaves 3 HP Standard Motor & High Static Drive Accessory
4000 786 1.70 813 1.81 841 1.91 867 2.02 893 2.12 919 2.22 943 2.32 966 2.41 989 2.50 1011 2.60
4500 806 2.06 834 2.19 861 2.31 886 2.43 911 2.56 935 2.67 960 2.79 983 2.90 1005 3.02 1028 3.13
5000 830 2.48 856 2.62 882 2.76 907 2.89 931 3.02 955 3.16 977 3.30 1001 3.44 1022 3.56 1045 3.70
5500 861 2.93 884 3.10 906 3.25 930 3.41 953 3.56 976 3.70 999 3.86 1021 4.00 1043 4.15 1064 4.31
6000 894 3.43 916 3.61 938 3.79 959 3.97 980 4.15 1000 4.31 1019 4.46 1040 4.62 1061 4.78 1082 4.95
5-HP Oversized Motor & Sheaves 5-HP Oversized Motor & Field Supplied Drive
(ii)
(ii)
5-HP Oversized Motor with Field Supplied Motor Sheave IVL40 required. Field Supplied Belt may be necessary.
*For 380V/60 Hz units, the oversized motor is used as the standard motor. Refer to "Motor & Sheave/Fan Speed" tables to determine operating range.
For Standard Evaporator Fan Speed (RPM), reference Table 50.
For Oversized Evaporator Fan Speed (RPM), reference Table 53.
Fan motor heat (MBH) = 3.15 x Fan BHP.
Notes:
Data includes pressure drop due to standard filters and wet coils. No accessories or options are included in pressure drop data. Refer to Table 54 to
determine additional static pressure drop due to other options/accessories.
Factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabular data will not result in nuisance tripping or premature
motor failure. Our product's warranty will not be affected.
Performance Data
