Trane Voyager TC* - Electrical Characteristics - Evaporator Fan Motor

RT-PRC024-EN 77
Electrical Data
(Standard Efficiency)
Table 63. Electrical Characteristics — Evaporator Fan Motor — 60 Cycle — Standard and Oversized Motor
Standard Evaporator Fan Motor Oversized Evaporator Fan Motor
Amps Amps
Tons
Unit Model
Number No. Volts Phase HP FLA LRA No. Volts Phase HP FLA LRA
12½ T/YC*150D3 1 208-230 3 3.00 10.6 81.0 1 208-230 3 5.00 16.7 109.8
T/YC*150D4 1 460 3 3.00 4.8 40.5 1 460 3 5.00 7.6 54.9
T/YC*150DW 1 575 3 3.00 3.9 31.0 1 575 3 5.00 6.1 41.6
T/YC*150DK 1 380 3 5.0 9.2 66.5 ———— — —
15 T/YC*180B3 1 208-230 3 3.00 10.6 81.0 1 208-230 3 5.00 16.7 109.8
T/YC*180B4 1 460 3 3.00 4.8 40.5 1 460 3 5.00 7.6 54.9
T/YC*180BW 1 575 3 3.00 3.9 31.0 1 575 3 5.00 6.1 41.6
T/YC*180BK 1 380 3 5.0 9.2 66.5 ———— — —
17½ T/YC*210C3 1 208-230 3 5.00 16.7 109.8 1 208-230 3 7.50 24.2 120.4
T/YC*210C4 1 460 3 5.00 7.6 54.9 1 460 3 7.50 11.0 74.0
T/YC*210CW 1 575 3 5.00 6.1 41.6 1 575 3 7.50 9.0 60.0
T/YC*210CK 1 380 3 7.5 13.3 83.5 ———— — —
20 T/YC*240B3 1 208-230 3 5.00 16.7 109.8 1 208-230 3 7.50 24.2 120.4
T/YC*240B4 1 460 3 5.00 7.6 54.9 1 460 3 7.50 11.0 74.0
T/YC*240BW 1 575 3 5.00 6.1 41.6 1 575 3 7.50 9.0 60.0
T/YC*240BK 1 380 3 7.5 13.3 83.5 ———— — —
25 T/YC*300B3 1 208-230 3 7.50 24.2 120.4 ———— — —
T/YC*300B4 1 460 3 7.50 11.0 74.0 ———— — —
T/YC* 300BW 1 575 3 7.50 9.0 60.0 — — — — — —
T/YC*300BK 1 380 3 7.5 13.3 83.5 ———— — —
* Indicates both downflow and horizontal units.
Table 64. Electrical Characteristics — Combustion Blower Motor (Gas/Electric)
Amps
Unit Model
Number
Heat Heating
Stages
HP RPM
(i)
(i)
High/Low Speed.
* Indicates both downflow and horizontal units.
Volts Phase FLA LRA
YC*150 Low 2 1/20 3500/2800 208-230 1 0.5 0.78
YC*180, 210, 240-300 Low 2 1/10 3500/2800 208-230 1 0.8 2.00
Table 65. Electrical Characteristics — Power Exhaust (Cooling and Gas/Electric)
Amps
Tons Volts Phase HP RPM FLA LRA
12½-25 208-230 1 3/4 1040 6.6 13.5
12½-25 460 1 3/4 1040 3.2 8.4
12½-25 575 1 3/4 1040 2.1 5.2
