Electrical Data
(Standard Efficiency)
Standard Indoor Motor Oversize Indoor Motor
Tons
Unit Model
Number
Heater Model
Number
Heater kW
Rating
Control
Stages MCA
Max Fuse Size
or Max Circuit
Breaker MCA
Max Fuse Size
or Max Circuit
Breaker
380 Volts Three Phase
12½ TC*150DK AYDHTRL418A/AYHHTRL418A 11.3 1 43 50 — —
AYDHTRK436A/AYHHTRK436A 22.6 2 55 60 — —
AYDHTRK454AAYHHTRK454A 33.8 2 76 80 — —
15 TC*180BK AYDHTRL418A/AYHHTRL418A 11.3 1 50 60 — —
AYDHTRK436A/AYHHTRK436A 22.6 2 55 60 — —
AYDHTRK454A/AYHHTRK454A 33.8 2 76 80 — —
17½ TC*210CK AYDHTRL436A/AYHHTRL436A 22.6 2 60 70 — —
AYDHTRL454A/AYHHTRL454A 33.8 2 81 90 — —
20 TC*240BK AYDHTRL436A/AYDHTRL436A 22.6 2 65 80 — —
AYDHTRL454A/AYDHTRL454A 33.8 2 81 90 — —
AYDHTRK472A/AYDHTRK472A 45.1 2 103 110 — —
25 TC*300BK AYDHTRL436A/AYDHTRL436A 22.6 2 70 80 — —
AYDHTRL454A/AYDHTRL454A 33.8 2 81 90 — —
AYDHTRK472A/AYDHTRK472A 45.1 2 103 100 — —
(i)
Heater kW ratings are at 380V for 380 unit.
* Indicates both downflow and horizontal units.
Table 62. Electrical Characteristics — Compressor Motor and Condenser Motor — 60 Cycle
Compressor Motors Condenser Fan Motors
Amps
(i)
(i)
For Compressor Motor and Condenser Fan Motors: Amp draw for each motor; multiply value by number of motors to determine total amps.
Amps
Tons
Unit Model
Number No. Volts Phase HP
(ii)
(ii)
HP for each compressor.
RPM RLA LRA No. Phase HP FLA LRA
12½ T/YC*150D3 2 208-230 3 6.00 3450 20.4 156 2 1 .50 3.2 8.8
T/YC*150D4 2 460 3 6.00 3450 10.8 75 2 1 .50 1.6 3.8
T/YC*150DW 2 575 3 6.00 3450 8.3 54 2 1 .50 1.3 3.2
T/YC*150DK 2 380 3 6.0 3450 13.1 70 2 1 .50 1.9 5.2
15 T/YC*180B3 2 208-230 3 9.30/5.10 3450 31.9/20.7 253/128 2 1 .50 3.2 8.8
T/YC*180B4 2 460 3 9.30/5.10 3450 16.3/10.0 113/63 2 1 .50 1.6 3.8
T/YC*180BW 2 575 3 9.30/5.10 3450 13.1/7.4 85/49 2 1 .50 1.3 3.2
T/YC*180BK 2 380 3 9.3/5.1 3450 19.7/12.1 125/64 2 1 .50 1.9 5.2
17½ T/YC*210C3 2 208-230 3 9.3/6.0 3450 31.5/20.8 253/156 2 1 1.00 5.5 18.3
T/YC*210C4 2 460 3 9.3/6.0 3450 15.9/10.0 113/75 2 1 1.00 2.9 9.3
T/YC*210CW 2 575 3 9.3/6.0 3450 12.8/8.2 85/54 2 1 1.00 2.0 5.7
T/YC*210CK 2 380 3 9.3/6.0 3450 19.2/12.1 125/70 2 1 1.00 3.5 8.5
20 T/YC*240B3 2 208-230 3 9.30 3450 31.7 253 2 1 1.00 5.5 18.3
T/YC*240B4 2 460 3 9.30 3450 16.2 113 2 1 1.00 2.9 9.3
T/YC*240BW 2 575 3 9.30 3450 13.0 85 2 1 1.00 2.0 5.7
T/YC*240BK 2 380 3 9.3 3450 19.6 125 2 1 1.00 3.5 8.5
25 T/YC*300B3 2 208-230 3 10.00 3450 36.6 278 2 1 1.00 5.5 18.3
T/YC*300B4 2 460 3 10.00 3450 17.9 124 2 1 1.00 2.9 9.3
T/YC*300BW 2 575 3 10.00 3450 14.9 92 2 1 1.00 2.0 5.7
T/YC*300BK 2 380 3 10.0 3450 21.7 137 2 1 1.00 3.5 8.5
Table 61. (continued) Unit Wiring with Electric Heat (Single Point Connection) — Standard and Oversized Motor, Downflow & Horizontal
